5G Small Cells
Enterprise, Indoor 5G
Product Description RTi-5Gn7841
-Baseband and RF chip NXP LS1046A + Qualcomm FSM10056
-RF Bands Supported n78, n41-Carrier Bandwidth. 100MHz, 40MHz
-Max Tx Power 24 dBm per radio path
-Modulation DL/UL - 256QAM/64QAM
-Antenna Internal OMNI
-Backhaul GE, SFP
-Power Supply DC 12V / POE++
-Power Consumption <35W
-Dimensions H/W/D - 200/200/62
Outdoor 5G Pico-cell
Product Description RT-5Gn78
-Baseband and RF chip NXP LS1046A + QCOM FSM10056 FSM10051
-RF Bands Supported n78
-Carriers Bandwidth. 100MHz-Max Tx Power 20 Watts per radio path
-Modulation DL/UL - 256QAM/64QAM
-Antenna External
-Backhaul GE, SFP
-Power Supply DC -48V
-Power Consumption 200W
-Dimensions H/W/D - 330/280/90
4G/LTE Small Cells
Enterprise, Dual Carrier; LTE
Product Description RT-E2nn
-Baseband and RF chip FSM9910/55 + FTR8900/8950
-RF Bands Supported 1, 3, 5, 7, 20, 40, 41, 42, 48-Number of LTE Carriers 2; and CA supported
-Max Tx Power 24 dBm per radio path
-Modulation DL/UL - 256QAM/64QAM
-Max user count 96 VoLTE / 192 Active / 384 connected
-Antenna Internal or External (via switch) OMNI
-Backhaul GE, SFP
-Power Supply DC 12V / POE++
-Power Consumption <24W
-Dimensions H/W/D - 220/220/40
Enterprise, Single Carrier; LTE
Product Description RT-E1nn
-Baseband and RF chip FSM9016 + FTR8930/8900
-RF Bands Supported 1, 3, 5, 7, 20, 40, 41, 42, 48
-Number of LTE Carriers 1 Carrier, 2x2 MIMO
-Max Tx Power 21 or 24 dBm per radio path
-TM 1, 2, 3, 4
-Timing GPS, NL, PTP
-Modulation DL/UL - 64QAM/64QAM
-Max user count 32 VoLTE / 64 Active / 96 connected
-Antenna Internal OMNI
-Backhaul GE, SFP
-Power Supply DC 12V / POE+
-Power Consumption <12W
-Diminsions H/W/D - 140/175/25
-Mounting Wall, Ceiling, Pole
-Baseband and RF chip FSM9016 + FTR8930/8900
-RF Bands Supported 1, 3, 5, 7, 20, 40, 41, 42, 48
-Number of LTE Carriers 1 Carrier, 2x2 MIMO
-Max Tx Power 21 or 24 dBm per radio path
-TM 1, 2, 3, 4
-Timing GPS, NL, PTP
-Modulation DL/UL - 64QAM/64QAM
-Max user count 32 VoLTE / 64 Active / 96 connected
-Antenna Internal OMNI
-Backhaul GE, SFP
-Power Supply DC 12V / POE+
-Power Consumption <12W
-Diminsions H/W/D - 140/175/25
-Mounting Wall, Ceiling, Pole
Residential Femtocell; LTE
Product Description RT-F1nn
-Baseband and RF chip FSM9016 + FTR8930
-RF Bands Supported 1, 3, 5, 7, 20, 40, 41, 42, 48
-Number of LTE Carriers 1 Carrier, 2x2 MIMO
-Max Tx Power 17dBm / 50mW
-Timing NL, GPS
-Modulation DL/UL - 64QAM/64QAM
-Max user count 16 VoLTE/32 Active/64 cnctd
-Antenna Internal OMNI
-Backhaul Ethernet
-Power Supply DC 12V
-Power Consumption <12W
-Diminsions H/W/D - 140/175/25
-Mounting Table Top
-Baseband and RF chip FSM9016 + FTR8930
-RF Bands Supported 1, 3, 5, 7, 20, 40, 41, 42, 48
-Number of LTE Carriers 1 Carrier, 2x2 MIMO
-Max Tx Power 17dBm / 50mW
-Timing NL, GPS
-Modulation DL/UL - 64QAM/64QAM
-Max user count 16 VoLTE/32 Active/64 cnctd
-Antenna Internal OMNI
-Backhaul Ethernet
-Power Supply DC 12V
-Power Consumption <12W
-Diminsions H/W/D - 140/175/25
-Mounting Table Top
